Class to estimate the density of the background per unit area. More...
#include <BackgroundEstimator.hh>
Public Member Functions | |
constructors and destructors | |
| BackgroundEstimator (const ClusterSequenceAreaBase &csa, const Selector &rho_range) | |
| ctor from a ClusterSequenceAreaBase with area | |
| BackgroundEstimator (const std::vector< PseudoJet > &jets, const Selector &rho_range) | |
| ctor from a list of jets | |
| BackgroundEstimator (const Selector &rho_range) | |
| Constructor that just sets the rho range. | |
| BackgroundEstimator () | |
| default ctor. | |
| ~BackgroundEstimator () | |
| default dtor | |
| double | rho () const |
| @ name retrieving fundamental information | |
| double | sigma () const |
| get sigma, the background fluctuations per unit area | |
| double | rho (const PseudoJet jet) |
| get rho, the median background density per unit area, locally at the position of a given jet. | |
| double | sigma (const PseudoJet &jet) |
| get sigma, the background fluctuations per unit area, locally at the position of a given jet. | |
| double | mean_area () const |
| @ name retrieving additional useful information | |
| unsigned int | n_jets_used () const |
| returns the number of jets used to actually compute the background properties in the last call of rho() or sigma() | |
| double | empty_area () const |
| Returns the estimate of the area (within the range defined by the selector) that is not occupied by jets. | |
| double | n_empty_jets () const |
| Returns the number of empty jets used when computing the background properties. | |
configuring behaviour | |
| void | set_cluster_sequence (const ClusterSequenceAreaBase &csa) |
| (re)set the cluster sequence (with area support) to be used by future calls to rho() etc. | |
| void | set_jets (const std::vector< PseudoJet > &jets) |
| (re)set the jets (which must have area support) to be used by future calls to rho() etc. | |
| void | set_selector (const Selector &rho_range_selector) |
| (re)set the selector to be used for future calls to rho() etc. | |
| void | reset () |
| Resets the class to its default state, including the choice to use 4-vector areas. | |
| void | set_use_area_4vector (bool use_it=true) |
By default when calculating pt/Area for a jet, it is the transverse component of the 4-vector area that is used in the ratiof  . | |
| bool | use_area_4vector () const |
| check if the estimator uses the 4-vector area or the scalar area | |
| void | set_provide_fj2_sigma (bool provide_fj2_sigma=true) |
| The FastJet v2.X sigma calculation had a small spurious offset in the limit of a small number of jets. | |
| void | set_jet_density_class (const FunctionOfPseudoJet< double > *jet_density_class) |
| Set a pointer to a class that calculates the quantity whose median will be calculated; if the pointer is null then pt/area is used (as occurs also if this function is not called). | |
|
const FunctionOfPseudoJet < double > * | jet_density_class () |
| return the pointer to the jet density class | |
| void | set_rescaling_class (const FunctionOfPseudoJet< double > *rescaling_class) |
| Set a pointer to a class that calculates the rescaling factor as a function of the jet (position). | |
|
const FunctionOfPseudoJet < double > * | rescaling_class () |
| return the pointer to the jet density class | |
Protected Member Functions | |
| void | _median_and_stddev (const std::vector< double > &quantity_vector, double n_empty_jets, double &median, double &stand_dev_if_gaussian, bool do_fj2_calculation=false) const |
| given a quantity in a vector (e.g. | |
Class to estimate the density of the background per unit area.
For a given event, this class calculated the median of the distribution of pt/Area for all jets in the event that pass some selection criterion.
Events are passed either in the form of a ClusterSequenceArea (in which case the jets used as those returned by "inclusive_jets()") or directly as a set of jets.
The selection criterion is typically a geometrical one (e.g. all jets with |y|<2) sometimes supplemented with some kinematical restriction (e.g. exclusion of the two hardest jets).
Beware: by default, to correctly handle partially empty events, the class attempts to calculate an "empty area", based (schematically) on
range.total_area() - sum_{jets_in_range} jets.area()
For ranges with small areas, this can be innacurate (particularly relevant in dense events where empty_area should be zero and ends up not being zero).
This calculation of empty area can be avoided if you supply a ClusterSequenceArea class with explicit ghosts (ActiveAreaExplicitGhosts). This is _recommended_!
Definition at line 154 of file BackgroundEstimator.hh.
| fastjet::BackgroundEstimator::BackgroundEstimator | ( | const ClusterSequenceAreaBase & | csa, |
| const Selector & | rho_range | ||
| ) |
ctor from a ClusterSequenceAreaBase with area
| csa | the ClusterSequenceArea to use |
| rho_range | a Selector that specifies the range over which jets will be considered |
Pre-conditions:
Note that selectors with e.g. hardest-jets exclusion do not have a well-defined area. For this reasons, it is STRONGLY advised to use an area with explicit ghosts.
Definition at line 92 of file BackgroundEstimator.cc.
References reset(), and set_cluster_sequence().
: _rho_range(rho_range){
// initialise things properly
reset();
// tell the BGE about the cluster sequence
set_cluster_sequence(csa);
}
| fastjet::BackgroundEstimator::BackgroundEstimator | ( | const std::vector< PseudoJet > & | jets, |
| const Selector & | rho_range | ||
| ) |
ctor from a list of jets
| jets | the jets to use |
| rho_range | the range over which jets will be considered |
Pre-conditions:
| fastjet::BackgroundEstimator::BackgroundEstimator | ( | const Selector & | rho_range | ) | [inline] |
Constructor that just sets the rho range.
The CSA or jets actually used for estimating the background must be passed later via set_cluster_sequence(...) or set_jets(...)
| rho_range | the range over which jets will be considered |
Definition at line 199 of file BackgroundEstimator.hh.
: _rho_range(rho_range) {
reset();
}
| fastjet::BackgroundEstimator::BackgroundEstimator | ( | ) | [inline] |
default ctor.
In order to use the BG estimator you then need to call set_selector(...) and also set_cluster_sequence(...) or set_jets(...)
Definition at line 206 of file BackgroundEstimator.hh.
{reset();}
| double fastjet::BackgroundEstimator::rho | ( | ) | const [inline] |
@ name retrieving fundamental information
get rho, the median background density oer unit area
Definition at line 219 of file BackgroundEstimator.hh.
{
if (_rho_range.takes_reference())
throw Error("The background estimation is obtained from a selector that takes a reference jet. rho(PseudoJet) should be used in that case");
_recompute_if_needed();
return _rho;
}
| double fastjet::BackgroundEstimator::rho | ( | const PseudoJet | jet | ) | [inline] |
get rho, the median background density per unit area, locally at the position of a given jet.
If the Selector associated with the range takes a reference jet (i.e. is relocatable), then for subsequent operations the Selector has that jet set as its reference.
Definition at line 240 of file BackgroundEstimator.hh.
{
_recompute_if_needed(jet);
double our_rho = _rho;
if (_rescaling_class != 0) {
our_rho *= (*_rescaling_class)(jet);
}
return our_rho;
}
| double fastjet::BackgroundEstimator::sigma | ( | const PseudoJet & | jet | ) | [inline] |
get sigma, the background fluctuations per unit area, locally at the position of a given jet.
If the Selector associated with the range takes a reference jet (i.e. is relocatable), then for subsequent operations the Selector has that jet set as its reference.
Definition at line 255 of file BackgroundEstimator.hh.
{
_recompute_if_needed(jet);
double our_sigma = _sigma;
if (_rescaling_class != 0) {
our_sigma *= (*_rescaling_class)(jet);
}
return our_sigma;
}
| double fastjet::BackgroundEstimator::mean_area | ( | ) | const [inline] |
@ name retrieving additional useful information
Returns the mean area of the jets used to actually compute the background properties in the last call of rho() or sigma()
Definition at line 271 of file BackgroundEstimator.hh.
{
_recompute_if_needed();
return _mean_area;
}
| double fastjet::BackgroundEstimator::empty_area | ( | ) | const [inline] |
Returns the estimate of the area (within the range defined by the selector) that is not occupied by jets.
The value is that for the last call of rho() or sigma()
The answer is defined to be zero if the area calculation involved explicit ghosts; if the area calculation was an active area, then use is made of the active area's internal list of pure ghost jets (taking those that pass the selector); otherwise it is based on the difference between the selector's total area and the area of the jets that pass the selector.
The result here is just the cached result of the corresponding call to the ClusterSequenceAreaBase function.
Definition at line 296 of file BackgroundEstimator.hh.
{
_recompute_if_needed();
return _empty_area;
}
| double fastjet::BackgroundEstimator::n_empty_jets | ( | ) | const [inline] |
Returns the number of empty jets used when computing the background properties.
The value is that for the last call of rho() or sigma().
If the area has explicit ghosts the result is zero; for active areas it is the number of internal pure ghost jets that pass the selector; otherwise it is deduced from the empty area, divided by
(the average pure-ghost-jet area).
The result here is just the cached result of the corresponding call to the ClusterSequenceAreaBase function.
Definition at line 312 of file BackgroundEstimator.hh.
{
_recompute_if_needed();
return _n_empty_jets;
}
| void fastjet::BackgroundEstimator::set_cluster_sequence | ( | const ClusterSequenceAreaBase & | csa | ) |
(re)set the cluster sequence (with area support) to be used by future calls to rho() etc.
| csa | the cluster sequence area |
Pre-conditions:
Note that selectors with e.g. hardest-jets exclusion do not have a well-defined area. For this reasons, it is STRONGLY advised to use an area with explicit ghosts.
Definition at line 123 of file BackgroundEstimator.cc.
References fastjet::ClusterSequenceAreaBase::has_explicit_ghosts(), fastjet::Selector::has_finite_area(), fastjet::ClusterSequence::inclusive_jets(), and fastjet::ClusterSequence::structure_shared_ptr().
Referenced by BackgroundEstimator().
{
_csi = csa.structure_shared_ptr();
// sanity checks
//---------------
// (i) check the alg is appropriate
_check_jet_alg_good_for_median();
// (ii) check that, if there are no explicit ghosts, the selector has a finite area
if ((!csa.has_explicit_ghosts()) && (!_rho_range.has_finite_area())){
throw Error("BackgroundEstimator: either an area with explicit ghosts (recommended) or a Selector with finite area is needed (to allow for the computation of the empty area)");
}
// get the initial list of jets
_included_jets = csa.inclusive_jets();
_uptodate = false;
}
| void fastjet::BackgroundEstimator::set_jets | ( | const std::vector< PseudoJet > & | jets | ) |
(re)set the jets (which must have area support) to be used by future calls to rho() etc.
; for the conditions that must be satisfied by the jets, see the Constructor that takes jets.
Definition at line 144 of file BackgroundEstimator.cc.
References fastjet::SharedPtr< T >::get(), fastjet::ClusterSequenceAreaBase::has_explicit_ghosts(), fastjet::Selector::has_finite_area(), and fastjet::ClusterSequenceStructure::validated_csab().
{
if (! jets.size())
throw Error("BackgroundEstimator::BackgroundEstimator: At least one jet is needed to compute the background properties");
// sanity checks
//---------------
// (o) check that there is an underlying CS shared by all the jets
if (! (jets[0].has_associated_cluster_sequence()) && (jets[0].has_area()))
throw Error("BackgroundEstimator::BackgroundEstimator: the jets used to estimate the background properties must be associated with a valid ClusterSequenceAreaBase");
_csi = jets[0].structure_shared_ptr();
ClusterSequenceStructure * csi = dynamic_cast<ClusterSequenceStructure*>(_csi());
const ClusterSequenceAreaBase * csab = csi->validated_csab();
for (unsigned int i=1;i<jets.size(); i++){
if (! jets[i].has_associated_cluster_sequence()) // area automatic if the next test succeeds
throw Error("BackgroundEstimator::set_jets(...): the jets used to estimate the background properties must be associated with a valid ClusterSequenceAreaBase");
if (jets[i].structure_shared_ptr().get() != _csi.get())
throw Error("BackgroundEstimator::set_jets(...): all the jets used to estimate the background properties must share the same ClusterSequence");
}
// (i) check the alg is appropriate
_check_jet_alg_good_for_median();
// (ii) check that, if there are no explicit ghosts, the selector has a finite area
if ((!csab->has_explicit_ghosts()) && (!_rho_range.has_finite_area())){
throw Error("BackgroundEstimator: either an area with explicit ghosts (recommended) or a Selector with finite area is needed (to allow for the computation of the empty area)");
}
// get the initial list of jets
_included_jets = jets;
// ensure recalculation of quantities that need it
_uptodate = false;
}
| void fastjet::BackgroundEstimator::set_use_area_4vector | ( | bool | use_it = true | ) | [inline] |
By default when calculating pt/Area for a jet, it is the transverse component of the 4-vector area that is used in the ratiof .
Calling this function with a "false" argument causes the scalar area to be used instead.
While the difference between the two choices is usually small, for high-precision work it is usually the 4-vector area that is to be preferred.
| use_it | whether one uses the 4-vector area or not (true by default) |
Definition at line 369 of file BackgroundEstimator.hh.
Referenced by reset().
{
_use_area_4vector = use_it;
_uptodate = false;
}
| void fastjet::BackgroundEstimator::set_provide_fj2_sigma | ( | bool | provide_fj2_sigma = true | ) | [inline] |
The FastJet v2.X sigma calculation had a small spurious offset in the limit of a small number of jets.
This is fixed by default in versions 3 upwards. The old behaviour can be obtained with a call to this function.
Definition at line 381 of file BackgroundEstimator.hh.
Referenced by reset().
{
_provide_fj2_sigma = provide_fj2_sigma;
_uptodate = false;
}
| void fastjet::BackgroundEstimator::set_jet_density_class | ( | const FunctionOfPseudoJet< double > * | jet_density_class | ) | [inline] |
Set a pointer to a class that calculates the quantity whose median will be calculated; if the pointer is null then pt/area is used (as occurs also if this function is not called).
Definition at line 389 of file BackgroundEstimator.hh.
{
_jet_density_class = jet_density_class;
_uptodate = false;
}
| void fastjet::BackgroundEstimator::set_rescaling_class | ( | const FunctionOfPseudoJet< double > * | rescaling_class | ) | [inline] |
Set a pointer to a class that calculates the rescaling factor as a function of the jet (position).
Note that the rescaling factor is used both in the determination of the "global" rho (the pt/A of each jet is divided by this factor) and when asking for a local rho (the result is multiplied by this factor).
Definition at line 404 of file BackgroundEstimator.hh.
{
_rescaling_class = rescaling_class;
_uptodate = false;
}
| void fastjet::BackgroundEstimator::_median_and_stddev | ( | const std::vector< double > & | quantity_vector, |
| double | n_empty_jets, | ||
| double & | median, | ||
| double & | stand_dev_if_gaussian, | ||
| bool | do_fj2_calculation = false |
||
| ) | const [protected] |
given a quantity in a vector (e.g.
pt_over_area) and knowledge about the number of empty jets, calculate the median and stand_dev_if_gaussian (roughly from the 16th percentile)
If do_fj2_calculation is set to true then this performs FastJet 2.X estimation of the standard deviation, which has a spurious offset in the limit of a small number of jets.
Definition at line 297 of file BackgroundEstimator.cc.
References n_jets_used().
{
// this check is redundant (the code below behaves sensibly even
// with a zero size), but serves as a reminder of what happens if
// the quantity vector is zero-sized
if (quantity_vector.size() == 0) {
median = 0;
stand_dev_if_gaussian = 0;
return;
}
vector<double> sorted_quantity_vector = quantity_vector;
sort(sorted_quantity_vector.begin(), sorted_quantity_vector.end());
// now get the median & error, accounting for empty jets
// define the fractions of distribution at median, median-1sigma
double posn[2] = {0.5, (1.0-0.6827)/2.0};
double res[2];
int n_jets_used = sorted_quantity_vector.size();
double total_njets = n_jets_used + _n_empty_jets;
for (int i = 0; i < 2; i++) {
double nj_median_pos;
if (do_fj2_calculation) {
nj_median_pos = (total_njets-1)*posn[i] - n_empty_jets;
} else {
nj_median_pos = (total_njets)*posn[i] - n_empty_jets - 0.5;
}
double nj_median_ratio;
if (nj_median_pos >= 0 && sorted_quantity_vector.size() > 1) {
int int_nj_median = int(nj_median_pos);
nj_median_ratio =
sorted_quantity_vector[int_nj_median] * (int_nj_median+1-nj_median_pos)
+ sorted_quantity_vector[int_nj_median+1] * (nj_median_pos - int_nj_median);
} else if (nj_median_pos > -0.5 && sorted_quantity_vector.size() >= 1 && !do_fj2_calculation) {
// in the LHS of this "bin", just keep a constant value (we could have
// interpolated to zero, but this might misbehave in cases where all jets
// are active, because it would go to zero too fast)
nj_median_ratio = sorted_quantity_vector[0];
} else {
nj_median_ratio = 0.0;
}
res[i] = nj_median_ratio;
}
median = res[0];
stand_dev_if_gaussian = res[0] - res[1];
}
1.7.4
